Cubello
Acoustic Guitar, Vocals, Playalongs
The Cubello is the new entry-level model in the large AER family. With two channels, a dynamically controlled 80 watts power amplifi er, 8“ full-range-speaker, two channels, two-band tone control per channel, reverb and delay, the Cubello amplifi es a wide range of instruments as well as vocals. This makes practicing or small gigs even more fun. With its Bluetooth support and the Aux input, nothing stands in the way of accompanying your favorite artists in your home. Of course, everything in the usual good AER sound quality. You will be amazed how much power is in this small device. We hope you enjoy using the Cubello!
Controls and connections:
INPUT:
- INPUT: instrument or line input, mono jack socket, ¼“ (6.35 mm)
- Gain: input level control
- Bass: bass tone control
- Treble: treble tone control
- INPUT: microphone input, combo socket for ¼“ (6.35 mm) jack or XLR, with following connection options: · XLR connector: microphone, balanced, with 48 V phantom power · stereo jack connector: microphone, balanced, without phantom power · mono jack connector: microphone, unbalanced, without phantom power
- Aux in: 3.5 mm (stereo) jack socket for Stereo general sources with line level, e.g. CD player
- Bluetooth: activation switch wireless audio up= off down= on
Effects:
- Pan: eff ect distribution control
- Select: eff ect selection switch up= reverb down= delay
- Level: level control internal eff ect
Mains & Master:
- Clip: overload indicator
- Master: master volume control
- Power: power on/off indicator lamp
- Headphones: output for headphones. The loudspeaker of the amplifi er is switched off when this socket is used.
- Line out: preamplifi er output post master and tone controls, with eff ects
Rear side:
- Power on/off: switch the Cubello on and off at the power on/ off switch of the mains inlet combination with integrated fuse holder.
Technical specifications:
- Input one : 6.3 mm (1/4”) input jack socket as high impedance line input stage and gain control.
- Input two : combined XLR/6.3 mm (1/4”) input jack socket as high-quality line- or balanced microphone input stage 48 V phantom power, gain control.
- Equalizer : two band tone controls
- Effects : digital reverb and delay
- Power amp : 80W / 4 ohms, dynamic control
- Speaker system : 8” Twin-Cone loudspeaker (200 mm) full range speaker
- Features : headphones, line out, Bluetooth®, Aux in
- Dimensions : 299 mm x 294 mm x 297 mm (11,77“ x 11,57“ x 11,69“) HxWxD
- Weight : 7,2 kg (15,9 lbs)
