Memory Toy
Pure analog delay for musicians who covet thick sound!
Electro-Harmonix melds heritage with select components to present the musician with up to 550ms of delay. Not a toy but a professional tool that bathes your axe with organic depth and dimension. The selectable chorus is a lush bonus. No one does analog like Electro-Harmonix!
Controls:
1. DELAY: Controls the delay time of your MEMORY TOY. The range of delay time is from 30ms to 550ms. Turn the delay time clockwise to increase the delay amount.2. BLEND: The BLEND control allows you to vary the mix of direct and delayed signals from 100% dry when set counter-clockwise to 100% wet at full clockwise.3. FEEDBACK: The FEEDBACK control increases the number of delay repeats or multiple echoes. At high settings the unit will begin to self-oscillate. Fairly high feedback with short delay settings produces a reverb type of effect.4. MOD Switch: When set to the ON position, the MOD switch will enable a slow modulation on the delay time similar to the chorus modulation of the Deluxe Memory Man. Set the MOD switch to the OFF position to disable all modulation.
Specifications:
- Circuit : Analog
- Bypass : True Bypass
- Audio : Mono
- Power Supply : 9V battery included (optional 9.6VDC-200mA power adapter not included)
- Dimensions (in) : 4.5 x 2.75 x 2.1
- Current Draw : 30mA
